Source Code Program Penggajian Vb Net Mysql
Assalamu'alaikum wr. wb.Jan 25, 2014 Pada Artikel Pintar VB kali ini adalah Download Gratis Source Code Program atau Aplikasi Dengan Visual Basic.Net. Beberapa aplikasi yang kami Uplode pada Blog ini memang kebanyakan berbentuk File Exe, namun ada beberapa yang kami berikan untuk anda Gratis file berbentuk Source Code.
Kali ini kita akan belajar bersama bagaimana membuat CRUD (Create, Read, Update, Delete) & search data dengan menggunakan VB.NET dan database MySQL.Aplikasi yang dibutuhkan ialah Microsoft Visual Studio, disini saya menggunakan Microsoft Visual Studio 2010. Sedangkan untuk database nya saya menggunakan MariaDB bawaan web server XAMPP karena OS nya windows.
Tampilan output-nya kira-kira seperti ini :
Tutorial :
1. Siapkan alat tempur yaitu Microsoft Visual Studio (versi terserah) dan install database MySQL (lebih enak install xampp yang sudah satu paket).
2. Buat project baru di vb.net dan jangan lupa pastikan sudah terinstall MySQL Connector Net (Anda dapat mendownload-nya disini).
3. Buat database perkuliahandb (nama optional), dan buat tabel mahasiswa (nama optional) dengan deskripsi field-field sebagai berikut.
4. Klik kanan pada project kita di bagian Solution Explorer (kanan) > Add Reference > .NET > MySql.Data
5. Buat desain form-form nya seperti hasil output program diatas (silakan di explore sesuai keinginan masing-masing), lalu berikan nama unique pada masing-masing komponen di dalamnya.
6. Buat modul baru dengan nama koneksi.vb dan kemudian sesuaikan script nya seperti dibawah ini
koneksi.vb
Source Code Program Penggajian Vb Net Mysql Access
Module koneksi
Public conn As New MySqlConnection
Public MySQLReader As MySqlDataReader
Public CMD As New MySqlCommand
Public DA As New MySqlDataAdapter
Public Sub konek(ByVal server As String, ByVal user As String, ByVal pass As String, ByVal db As String)
If conn.State = ConnectionState.Closed Then
Dim myString As String = 'server=' & server & ';user=' & user & ';password=' & pass & ';database=' & db
Try
conn.ConnectionString = myString
conn.Open()
Catch ex As MySql.Data.MySqlClient.MySqlException
MessageBox.Show('Koneksi Gagal' & vbCrLf & 'Mohon cek apakah server sudah siap!', 'Koneksi ke server', MessageBoxButtons.OK, MessageBoxIcon.Warning)
End Try
End If
End Sub
Public Sub disconnect()
Try
conn.Open()
Catch ex As MySql.Data.MySqlClient.MySqlException
End Try
End Sub
End Module
Form1.vb
Imports MySql.Data.MySqlClient
Public Class Form1
Dim conn As New MySqlConnection('Server=localhost; user=root; database=perkuliahandb')
Dim perintah As New MySqlCommand
Dim data As New MySqlDataAdapter
Dim ds As New DataSet
Private Sub tampildata()
Dim dt As DataTable
Dim adapter As MySqlDataAdapter
Dim sqlstr As String
Dim data As Integer
sqlstr = 'SELECT * FROM mahasiswa'
adapter = New MySqlDataAdapter(sqlstr, conn)
dt = New DataTable
data = adapter.Fill(dt)
If data > 0 Then
tabelMhs.DataSource = dt
tabelMhs.AutoSizeColumnsMode = DataGridViewAutoSizeColumnMode.Fill
tabelMhs.Columns(0).HeaderText = 'NIM'
tabelMhs.Columns(1).HeaderText = 'NAMA'
tabelMhs.Columns(2).HeaderText = 'TEMPAT'
tabelMhs.Columns(3).HeaderText = 'TGL LAHIR'
tabelMhs.Columns(4).HeaderText = 'JENIS KELAMIN'
tabelMhs.Columns(5).HeaderText = 'ALAMAT'
Else
tabelMhs.DataSource = Nothing
End If
bersih()
End Sub
Private Sub bersih()
txtNim.Text = '
txtNama.Text = '
txtAlamat.Text = '
txtTempat.Text = '
cbJk.SelectedIndex = -1
dtpTgl.Text = '
txtNim.Focus()
End Sub
Private Sub btnSimpan_Click(ByVal sender As System.Object, ByVal e As System.EventArgs) Handles btnSimpan.Click
conn.Open()
Try
perintah.CommandType = CommandType.Text
perintah.CommandText = 'INSERT INTO mahasiswa (nim, nama, jekel, tempat, tgl_lahir, alamat) VALUES (' & txtNim.Text & ', ' & txtNama.Text & ', ' & cbJk.Text & ', ' & txtTempat.Text & ', ' & dtpTgl.Text & ', ' & txtAlamat.Text & ')'
perintah.Connection = conn
perintah.ExecuteNonQuery()
MsgBox('Data berhasil disimpan', MsgBoxStyle.Information, 'Informasi')
Catch ex As Exception
MsgBox('Data gagal disimpan' + ex.Message, MsgBoxStyle.Critical)
End Try
conn.Close()
tampildata()
End Sub
Private Sub Form1_Load(ByVal sender As System.Object, ByVal e As System.EventArgs) Handles MyBase.Load
konek('localhost', 'root', ', 'perkuliahandb')
tampildata()
dtpTgl.Format = DateTimePickerFormat.Custom
dtpTgl.CustomFormat = 'yyyy/MM/dd'
btnEdit.Enabled = False
btnHapus.Enabled = False
btnBatal.Enabled = False
End Sub
Private Sub btnKeluar_Click(ByVal sender As System.Object, ByVal e As System.EventArgs) Handles btnKeluar.Click
Me.Close()
End Sub
Private Sub btnEdit_Click(ByVal sender As System.Object, ByVal e As System.EventArgs) Handles btnEdit.Click
conn.Open()
Try
Dim perintah As New MySql.Data.MySqlClient.MySqlCommand
perintah.CommandType = CommandType.Text
perintah.CommandText = 'UPDATE mahasiswa SET nama = ' & txtNama.Text & ' , jekel = ' & cbJk.Text & ' , tempat = ' & txtTempat.Text & ' , tgl_lahir = ' & dtpTgl.Text & ' , alamat = ' & txtAlamat.Text & ' WHERE nim = ' & txtNim.Text & ''
perintah.Connection = conn
perintah.ExecuteNonQuery()
MySQLReader = perintah.ExecuteReader
MsgBox('Data berhasil diubah', MsgBoxStyle.Information, 'Informasi')
Catch ex As Exception
MsgBox('Data gagal diubah' + ex.Message, MsgBoxStyle.Critical)
End Try
conn.Close()
tampildata()
btnSimpan.Enabled = True
txtNim.Enabled = True
txtNim.Focus()
End Sub
Private Sub btnHapus_Click(ByVal sender As System.Object, ByVal e As System.EventArgs) Handles btnHapus.Click
Dim hasil As MsgBoxResult = MessageBox.Show('Apakah data ingin dihapus?', 'Pesan', MessageBoxButtons.OKCancel, MessageBoxIcon.Warning)
If hasil = vbOK Then
conn.Open()
perintah.Connection = conn
perintah.CommandType = CommandType.Text
perintah.CommandText = 'DELETE FROM mahasiswa WHERE nim = ' & txtNim.Text & ''
perintah.ExecuteNonQuery()
conn.Close()
End If
tampildata()
btnSimpan.Enabled = True
txtNim.Focus()
End Sub
Private Sub tabelMhs_CellClick(ByVal sender As Object, ByVal e As System.Windows.Forms.DataGridViewCellEventArgs) Handles tabelMhs.CellClick
Dim i As Integer
i = Me.tabelMhs.CurrentRow.Index
With tabelMhs.Rows.Item(i)
Me.txtNim.Text = .Cells(0).Value
Me.txtNama.Text = .Cells(1).Value
Me.cbJk.Text = .Cells(4).Value
Me.txtTempat.Text = .Cells(2).Value
Me.dtpTgl.Text = .Cells(3).Value
Me.txtAlamat.Text = .Cells(5).Value
End With
txtNim.Enabled = False
btnSimpan.Enabled = False
btnEdit.Enabled = True
btnHapus.Enabled = True
btnBatal.Enabled = True
End Sub
Private Sub txtCari_KeyPress(ByVal sender As Object, ByVal e As System.Windows.Forms.KeyPressEventArgs) Handles txtCari.KeyPress
Dim dt As DataTable
Dim adapter As MySqlDataAdapter
Dim sqlstr As String
Dim data As Integer
If cbCari.Text = 'NIM' Then
sqlstr = 'SELECT * FROM mahasiswa WHERE nim LIKE '%' & txtCari.Text & '%'
ElseIf cbCari.Text = 'Nama' Then
sqlstr = 'SELECT * FROM mahasiswa WHERE nama LIKE '%' & txtCari.Text & '%'
Else
sqlstr = 'SELECT * FROM mahasiswa WHERE nim or nama LIKE '%' & txtCari.Text & '%'
End If
adapter = New MySqlDataAdapter(sqlstr, conn)
dt = New DataTable
data = adapter.Fill(dt)
If data > 0 Then
tabelMhs.DataSource = dt
tabelMhs.AutoSizeColumnsMode = DataGridViewAutoSizeColumnMode.Fill
tabelMhs.Columns(0).HeaderText = 'NIM'
tabelMhs.Columns(1).HeaderText = 'NAMA'
tabelMhs.Columns(2).HeaderText = 'JEKEL'
tabelMhs.Columns(3).HeaderText = 'TEMPAT'
tabelMhs.Columns(4).HeaderText = 'TGL. LAHIR'
tabelMhs.Columns(5).HeaderText = 'ALAMAT'
Else
tabelMhs.DataSource = Nothing
'MsgBox('Data tidak ditemukan!', MsgBoxStyle.Information, 'Informasi')
End If
End Sub
Private Sub btnBatal_Click(ByVal sender As System.Object, ByVal e As System.EventArgs) Handles btnBatal.Click
bersih()
txtNim.Enabled = True
btnSimpan.Enabled = True
btnEdit.Enabled = False
btnHapus.Enabled = False
End Sub
End Class
8. Selesai. Selamat dan semoga berhasil :)
Kira-kira seperti itu tutorial pembuatannya. Cukup mudah bukan?
Bagi teman-teman yang belum bisa praktek atau ingin mendapatkan langsung source code jadi + database nya. Silakan download pada link dibawah ini :
Catatan :
Jika Anda mendownload source code ini dan ketika dijalankan terjadi error seperti gambar dibawah ini,
Maka solusinya adalah klik kanan project kita di Solution Explorer (biasanya di kanan atas), kemudian cari bagian menu References dan remove dulu bagian MySql.Data nya (biasanya paling atas). Setelah itu ulangi Add Reference seperti pada tutorial nomor 4 diatas.
* Referensi :
Modul Praktikum Pemrograman Terstuktur (Pertemuan ke IXb dan Xa) jurusan Teknik Informatika Semester 2, yang diampu oleh Dosen Ahmad Abdul Chamid, S.Kom., M.Kom. di Universitas Muria Kudus. Tetapi source code sudah di modifikasi sesuai kebutuhan oleh YukCoding.
Semoga bermanfaat, happy coding :)
Wassalamu'alaikum wr. wb.
Project: Student’s Individual Inventory Record System in VB.NET with source code
About Project
Student’s Individual Inventory Record System project is developed using VB.NET. The Project is based on the concept of managing student’s inventory record. Talking about the project, Before entering the dashboard, the user should pass through the login system to get access. There are two accounts; Admin and Staff. After logging as staff, he/she can manage students, excuse slip and more.
About System
Talking about the features of Student’s Individual Inventory Record System, he/she can manage student details by entering details such as student id, name, gender, course, year, section, civil status, D.O.B, height, contact information with some educational, home and family background. The staff can also manage excuse slip by entering its details, guidance office, and view reports.
About Admin Panel
Talking about the admin panel, the admin has full control of the system. The admin can manage student details by entering details such as student id, name, gender, course, year, section, civil status, D.O.B, height, contact information with some educational, home and family background. The admin can manage/add a course by entering course code and description, excuse slip by entering it’s details, guidance office, and view reports. It also features user management for easy management of the system.
Student’s Individual Inventory Record System project helps the user for easy management of students informations and reports. For handling data, MySQL is used as a database. This project is easy to operate and understood by the users. To run this project you must have installed Visual Studio IDE and XAMPP on your PC. Student’s Individual Inventory Record System in VB.NET is free to download with source code. For the project demo, have a look at the video below.
Features:
- Login System
- Manage Students
- Manage course
- Guidance office
- View Reports
- User management system
How To Run??
Start Apache and MySQL in XAMPP, and follow the given steps
Connecting Database (MySQL)
1st Step: Open a browser and go to URL “http://localhost/phpmyadmin/”
2nd Step: Then, click on the databases tab
3rd Step: Create database naming “
4th Step: Click on browse file and select “dbstudentindividualinventory.sql” file which is inside “Database (MySQL)” folder
5th Step: Click on go.
After Creating Database,
Final Step: Open “StudentIndividualInventory.sln” file.
Insert the username and password which is provided inside the “READ ME FIRST.txt” file.
Other Requirements To Run The Project:
- Connector/NET
- MySQL Connector/ODBC
LOGIN DETAILS ARE PROVIDED IN “READ ME FIRST.txt” FILE INSIDE THE PROJECT FOLDER
DOWNLOAD STUDENT’S INDIVIDUAL INVENTORY RECORD SYSTEM IN VB.NET: CLICK THE BUTTON BELOW
(Before you proceed to download, please complete the captcha below)
Got stuck or need help customizing Student’s Individual Inventory Record System as per your need, just sign up to ask your questions in the forum or just comment down below and we will do our best to answer your question ASAP.
